Arcadia Lighting WPFT07 Series Wall Light

Sale!
Arcadia Lighting WPFT07 Series Wall Light

Arcadia Lighting WPFT07 Series Wall Light

Original price was: $5,999.40.Current price is: $4,352.59.

94 in stock

SKU: WPFT07 Category:

Description

Arcadia Lighting WPFT07 Series Wall Light

Features

  • Die-Cast Aluminum on Front and Back Housing
  • Full Cutoff and Complaint with Dark Sky Requirements
  • Mounting via J-box or Surface Conduit
  • Adjustable Lumen Output with Four Lument Setting 100%, 80%, 60%, 40%
  • Switchable Color Temperature 3000K/4000K/5000K
  • Casting Thermally Conducts LED Heat to Optimize Performance and Long Life
  • Pre-Installed Photocell Button, PIR Sensor and Emergency Battery Available
  • UL listed for Wet Locations
  • 5-year limited warranty

Product Details

Power Light Output Power Input Operating Temperature Efficacy
70W – 135W 4,200 lm – 20,000 lm 120-277V, 347/480V -40°F – 131°F Up to 143 lm/W

Certifications Photocell Emergency Battery CRI Color Temperature
UL/DLC Button 8W 900 lm 70 CRI 4000K, 5000K

Finish Driver Light Distribution
DB, B, W 1-10V Dimming Type 3

Performance Data

WPFT07-70W

Switch Setting System Watts CRI 3000K (Lumens) 3000K (LPW) 4000K (Lumens) 4000K (LPW) 5000K (Lumens) 5000K (LPW)
100% 70W 70 9,500 lm 136 lm/W 10,000 lm 143 lm/W 9,700 lm 139 lm/W
80% 56W 70 7,800 lm 139 lm/W 8,200 lm 146 lm/W 7,950 lm 142 lm/W
60% 42W 70 6,000 lm 143 lm/W 6,300 lm 150 lm/W 6,100 lm 145 lm/W
40% 28W 70 4,100 lm 146 lm/W 4,300 lm 154 lm/W 4,200 lm 150 lm/W

WPFT07-125W

Switch Setting System Watts CRI 3000K (Lumens) 3000K (LPW) 4000K (Lumens) 4000K (LPW) 5000K (Lumens) 5000K (LPW)
100% 125W 70 17,100 lm 137 lm/W 18,000 lm 144 lm/W 17,500 lm 140 lm/W
80% 100W 70 14,000 lm 140 lm/W 14,800 lm 148 lm/W 14,400 lm 144 lm/W
60% 75W 70 10,800 lm 144 lm/W 11,400 lm 152 lm/W 11,000 lm 147 lm/W
40% 50W 70 7,400 lm 148 lm/W 7,750 lm 155 lm/W 7,500 lm 150 lm/W

WPFT07-135W

Switch Setting System Watts CRI 3000K (Lumens) 3000K (LPW) 4000K (Lumens) 4000K (LPW) 5000K (Lumens) 5000K (LPW)
100% 135W 70 19,000 lm 141 lm/W 20,000 lm 148 lm/W 19,400 lm 144 lm/W
80% 108W 70 15,700 lm 145 lm/W 16,400 lm 152 lm/W 16,000 lm 148 lm/W
60% 81W 70 12,000 lm 148 lm/W 12,650 lm 156 lm/W 12,200 lm 151 lm/W
40% 54W 70 8,150 lm 151 lm/W 8,600 lm 159 lm/W 8,300 lm 154 lm/W
